Deep learning based human and vehicle targets classification of Motion Detection 2.0
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video input
Audio via coaxial cable
Up to 10-ch IP camera input (up to 5 MP)
Encoding ability up to 1080p lite @ 15 fps
Max. 1200 m for 720p HDTVI signal
Smart Detection
AI motion detection 2.0 — classifies people vs. vehicles, dramatically cutting false alarms from leaves, headlights, shadows, etc.
Quick object search — find footage by searching for a specific event/object type instead of scrubbing manually
Camera Compatibility
8 analog channels (BNC) — supports HDTVI, AHD, HDCVI, and standard analog cameras up to 1080p
Plus 2 IP camera channels (expandable up to 10 total) — supports IP cameras up to 5MP, higher than the 4-channel DVR's IP support
Good option for customers wanting a mixed analog + IP setup, or simply more channels than the 4-ch model
Viewing & Output
HDMI + VGA simultaneous output, up to 1080p
8-channel synchronous playback — review all cameras at once
Audio
1 audio input/output, expandable to 8 channels via coaxial cable
Two-way audio support
Recording & Storage
1 SATA bay, supports up to 4TB
Efficient H.265 Pro+/H.265 Pro/H.265 compression
Note: main stream frame rate caps at 15 fps at 1080p/720p (lower than the 4-ch DVR's ~25/30fps) — worth mentioning to customers who want smoother high-res footage, since this model is more geared toward channel count than per-camera frame rate
Remote Access
Hik-Connect app support
Up to 64 simultaneous remote connections — much higher than the 4-ch model, suited for businesses with multiple staff monitoring
Build & Specs
Dimensions: 200 × 200 × 48 mm, ~1 kg (without HDD)
